RACEWORKS 1200CC MODIFIED BOSCH 3/4 LENGTH INJECTOR 11MM | INJ-504-11MM

RACEWORKS 1200CC RACEWORKS (MODIFIED BOSCH) 3/4 LENGTH INJECTOR 11mm

Modified/High Flowed Bosch Injector
Size: 1200cc (114 Lb/hr) @ 3bar and 1400cc (133Lb/hr) @ 4bar.
Impedance: High (12 Ohms)
Plug: Denso. Top O-Ring: 11mm.
Ethanol; Methanol Safe
Spray Pattern: Narrow Cone
Spray Direction: Straight

Flow variance is +/- 1.5% (3% Total)

Download Injectors Size Charts PDF

Direct fit applications
Mitsubishi Lancer CE I4
Mitsubishi Legnum EC5W V6 Twin Turbo I6
Subaru Forester SF/SG GT H4 Turbo
Subaru Forester SG/SH XT H4 Turbo 03-2005 Onwards
Subaru Forester SG/SH H4
Subaru Impreza GD/GE/GG/GV/GH/GJ/GK/GR H4 Turbo
Subaru Liberty 3rd Gen H4 Twin Turbo
Subaru Liberty 4th Gen H4 2.5L Turbo
Subaru Liberty 4th Gen H6
Subaru Liberty 5th Gen H4/H6
Toyota JZX100 I6
Toyota Soarer JZZ30 I6

Injectors are a direct fit physically, but as with all Raceworks Injectors, will require a tune. While the vehicles listed above are direct fit, the injector can be used in many other applications with the appropriate extensions, o-rings or plug adapters. SeeInjector Upgrade Guidefor more details.

FLYWHEEL POWER FIGURES (ESTIMATED) PER INJECTOR
