RACEWORKS EFI 700HP 3PORT FUEL PRESSURE REGULATOR AN-6 PORTS
Specifications Part Number 2 x AN-6 Inlets and AN-6 Return. 1/8in NPT Gauge Port. Base Pressure Range of 40-75PSI (2.75-5.2Bar). Boost Referenced (1:1 Ratio). Boost Reference Port is 1/16in NPT. Dimensions are 94mm high, 62mm wide and 60mm deep with no fittings. E85 and PUMP Fuel Safe. FPR-501BK
Bypass Rate of 550LPH.
Fittings to Suit
AN Male Flare Straight
| AN-4 | RWF-920-04-06BK |
| AN-6 | RWF-920-06BK |
| AN-8 | RWF-920-08-06BK |
| AN-10 | RWF-920-10-06BK |
| AN-12 | RWF-920-12-06BK |
Barb Straight;
| AN-6 to 5/16in Barb | RWF-414-06-05BK |
| AN-6 to 3/8in barb | RWF-414-06-06BK |
AN Male Flare Straight Long
| AN-10 | RWF-920-06LBK |
AN Male Flare 45deg
| AN-10 | RWF-922-06BK |
AN Male Flare 90deg
| AN-10 | RWF-923-06BK |
